V3800-TIE5H
- EPA Tier 4
- CARB Tier 4
- EU Stage V
V3800-TIE5H
- EPA Tier 4
- CARB Tier 4
- EU Stage V
Performance Curves
Features and Benefits
Proven Reliability and Technology
The latest technology and strong performance-two things customers expect from Kubota engines. We continue to provide both through the pursuit of excellence in emissions compliance and progress toward fully electronic controlled engines. These key areas allow Kubota to offer flexibility in the products and services we provide to customers worldwide.
Advanced DPF Technology
Diesel Particulate Filters (DPF) are essential to comply EPA/ CARB Tier 4 and EU Stage V emission regulations. With many years of experience in DPF engines, Kubota has developed a DPF technology that enables automatic regeneration even at a low rpms, giving your product a competitive edge. The technology has also made long service intervals possible, helping to minimize downtime and maintenance worries.
Emissions Compliance
Meeting rigid emissions regulations can be a challenge for any company. Our Kubota V3 Series engines have been designed to comply with various emissions regulations, including the stringent regulations: EPA/CARB Tier 4 and EU Stage V. In addition, innovative and reliable aftertreatment solutions, such as Diesel Particulate Filters (DPF) unit, have been applied to it.
Fuel Efficiency
With Kubota’s technology and experience, Common Rail
System (CRS) is optimized and realizing low fuel consumption.
Flexibility is a must when working with customers in different
countries who have different engine needs. Since Kubota V3
Series engines have evolved along every step in meeting the
requirements of each EPA Tier, we are able to provide our
customers worldwide with engines certified for the appropriate
emissions regulat ions. In addi t ion, we have designed
aftertreatment units with minimum impact for easy installation.
Flexibility
Engine Specifications
| Engine model | V3800-TIE5H |
|---|---|
| Emission regulation | EPA/CARB Tier 4 + EU Stage V |
| Type | Vertical, water cooled 4-cycle DI diesel engine |
| Cylinders | 4 |
| Bore and Stroke mm (in) |
100.0 × 120.0 (3.937 × 4.724) |
| Displacement L (cu.in) |
3.769 (230.0) |
| Aspiration | Turbocharged + Turbo After Cooler |
| Aftertreatment | DOC + DPF + SCR |
| Rated output / speed*1 kW (HP) / rpm |
96.4 (129.3) / 2400 |
| Maximum torque / speed*1 Nm (lb-ft) / rpm |
446.4 (329.4) / 1800 |
| Combustion system | Direct Injection |
| Fuel system | Common Rail System |
| Length x Width x Height*2 (without aftertreatment unit) mm (in) |
720 × 617 × 872 (28.3 × 24.3 × 34.3) |
| Length x Width x Height*3 (with aftertreatment unit) mm (in) |
864 × 638 × 1226 (34.0 × 25.1 × 48.26) |
| Dry weight kg (lb) |
423 (933) |
Specifications are subject to change without notice.
Dimensions and dry weight are according to Kubota's standard specification.
Dimensions and weight depend on completed specifications.
- *1: SAE J1995 gross intermittent
- *2: Exclude cooling fan and exclude aftertreatment unit
- *3: Exclude cooling fan and include aftertreatment unit on engine
Dimensions
